FAB- 121P

Features
Stainless steel front bezel Display
Flat front panel touch screen
Projected Capacitive Touch or Glass (Option)
Wide range DC 9~36V power input
IP66 compliant front panel / IP69K for option
VGA, DP, DVI/HDMI input
OSD on the rear side
System Power LED light
High brightness LCD for option
Specifications
I/O Port
VGA 1 x VGA
DVI 1 x DVI-D (share with HDMI)
DP 1 x DP
HDMI 1 x HDMI (share with DVI-D)
Audio 1 x Audio line-in phone jack
OSD Control Membrane OSD at rear side On board controller, extendable key pad from connector
Power 1 x 3-pin terminal block for DC 9~36V power input
LED Light 1 x system power LED light
Speaker 1 x 2W speaker for option
Others  1 x USB type B for touch control Optional I/O: 1 x Speaker
Dispalay
Display Type
 Standard 21.5 TFT LCD
 High Brightness Optional  21.5 TFT LCD
Max. Resolution
Standard  1920x 1080
High Brightness Optional  1920x 1080
Max. Color
Standard 16.7M
 High Brightness Optional  16.7M
Luminance (cd/m2)
Standard 250
 High Brightness Optional  1000
View Angle
Standard 178(H) / 178(V)
 High Brightness Optional 178(H) / 178(V)
Contrast
Standard  300:1
 High Brightness Optional 300:1
Backlight Lifetime
Standard 30,000 hrs
 High Brightness Optional  50,000 hrs
Touch Screen
Type Projected Capacitive Touch (For FABS-107P model) Glass-AR (For FABS-107G model)
Interface  USB Interface
Light Transmission(%)  over 90%
Power
Power Input  DC 9~36V
Power Consumption TBD
Mechanical
Construction Aluminum die-casting chassis
Mounting Panel mount / VESA mount 100 x 100
Dimension (WxHxD) 573.8 x 378.8 x 59.8 mm
Net Weight TBD
IP Rating IP66 compliant front panel / IP69(option)
Environmental
Operating Temperature  0~50°C
Storage Temperature   -30~70 °C
Storage Humidity  10~90% @40 °C non-condensing
Certificate  CE/FCC, Class A
